| Display | 14.0” FHD (1920 x1080)
1000 nits DynaVue® sunlight-readable display with capacitive multi-touch screen
User-selectable touch mode for Finger/Water, Glove, or Stylus programmable function |
Operating System | Windows® 10 Pro 64-bit |
| CPU | Intel® Core™ i7-1185G7 vPro™ (11th Gen) 3.0GHz processor with Turbo Boost Technology up to 4.8GHz, 12MB cache
Intel® Core™ i7-1165G7 (11th Gen) 2.8GHz processor with Turbo Boost Technology up to 4.7GHz, 12MB cache
Intel® Core™ i5-1145G7 vPro™ (11th Gen) 2.6GHz processor with Turbo Boost Technology up to 4.4GHz, 8MB cache
Intel® Core™ i5-1135G7 (11th Gen) 2.4GHz processor with Turbo Boost Technology up to 4.2GHz, 8MB cache |
| Memory | 2 slots 8GB up to 64GB (3200MHz DDR4) |
| Storage | Main: 256GB/512GB/1TB NVME PCIE SSD
Optional 256GB/512GB/1TB SATA SSD
Optional OPAL 2.0 SSD
Optional 2nd/3rd storage (SATA SSD)1 |
| Graphics | Intel® Iris® Xe Graphics
Optional NVIDIA® GEFORCE GTX 10501 |
| Camera | Integrated 2.0 MP web-cam with shutter design
Optional IR camera for Windows Hello1 |
| Audio | Integrated microphone
Intel® High Definition Audio Compliant
Integrated speaker x 2
Keyboard volume and mute controls |
Media Bay
(One Option Only) | Optional DVD super Multi
Optional 2nd battery
Optional SATA SSD |
Expansion Box | Optional PCI-Express 3.0 (2 slots)
Optional discrete VGA
Optional storage extension with RAID 0/1/5/10
Optional military-grade connectors |
| I/O Ports | Thunderbolt 4 (type C) x 1
USB 3.2 Gen2 (type C) x 1 (support DP)
USB 3.2 Gen2 (type A) x 1
USB 3.2 Gen1 (type A) x 1
USB 2.0 (type A) x 1
Audio in/out (combo jack) x 1
microSD card (microSDXC) x 1
10/100/1000 Ethernet (RJ45) x 2
VGA port (D-sub,15-pin) x 1
HDMI port (type A) x 1
Serial port (RS232 : D-sub,9-pin) x 25
Docking connector (41-pin Pogo) x 1
SIM card x 1
Smart card reader x 1
DC-In jack x 1
ExpressCard 54 x 1 (default) or PCMCIA Type II x 1
Optional RF antenna pass-through for GPS, WWAN, and WLAN |
Keyboard & Pointing Device | 2 user-definable keys (P1/P2)
RF signal slide-switch
Standard membrane keyboard with LED backlight |
| Communications | Integrated 10/100/1000 Ethernet
Intel® Wi-Fi 6 AX201 (802.11 ax)
Bluetooth® V5.2
Optional dedicated GPS module (UBLOX-NEO-M8N)
Optional 4G LTE multi-carrier mobile broadband
Optional RF antenna pass-through for GPS, WWAN, and WLAN |
| Security | Intel® vPro™ Technology (per CPU options)
TPM 2.0
NIST BIOS compliant
Easy removable SSD
Smart card reader
Stealth mode
Night vision mode
Kensington lock
Optional Windows Hello
Optional fingerprint scanner
Optional HF/LF RFID reader |
| Power | AC adapter : 100-240V, 50Hz-60Hz, 90W
Optional AC adapter (100-240V, 50Hz-60Hz, 120W), with NVIDIA® VGA
Main battery Li-Ion, 10.8V, 7800mAh, 16 hours
Optional 2nd battery Li-Ion 10.8V, 4700mAh, 9 hours
Optional bridge battery : 5 minutes swap time |
Dimension & Weight | 356 mm (L) x 280 mm (W) x 50 mm (H)
3.6 kg |
| Warranty | 3-year limited warranty standard |
